Video Intercom Door Station·User Manual
5
3 Typical Application
3.1 Typical Application of DS-KV8X02-IM
Please refer to the following figure for typical application of DS-KV8102-IM/
DS-KV8202-IM/ DS-KV8402-IM door station.
Master Station
Video/Audio
Distributor
Client Software
Door Station
IP Camera
LAN
Card Reader
Network Cable
Optical Fiber
One Resident
RS-485
Wi-Fi/3G/4G
Resident 1
1F
2F
Resident 2
Resident 1Resident 2
Indoor
Extension 2
Indoor
Extension 2
House
Internet
App
Wi-Fi
Wi-Fi/3G/4G
Figure 3-1 Typical Application of DS-KV8X02-IM
