Video Intercom Door Station·User Manual
6
3.2 Typical Application of DS-KV8102-XP
Please refer to the following figures for typical applications of DS-KV8102-IP/
DS-KV8102-VP door station.
Switch
Client Software
Network Cable
Optical Fiber
Door Station
Resident 1
IPC
Video/Audio
Distributor
LAN
Indoor
Extension 1
Indoor
Extension 2
Master Station
Card Reader
RS-485/3G/4G
Wi-Fi
House
Internet
App
Wi-Fi
Wi-Fi/
3G/4G
Figure 3-2 Typical Application of DS-KV8102-XP
