HIKVISION DS-MCW405 User Manual

DS-MCW405/32G/GPS/WIFI Body Camera User Manual
UM DS-MCW405/32G/GPS/WIFI 042021NA 18
•
Check it to enable quick charging. When the device is being charged, you cannot record or operate
the device, which can shorten the charging time.
•
Uncheck it to disable quick charging. When the device is being charged, you can operate it normally.
NOTE: Reboot the device to have the settings take effect.
3.5.9 Enable Overwritten Record
You can enable overwritten record to keep recording when the available memory is insufficient, the
existing recorded videos will be overwritten.
If you enable overwritten record, back up important data in time or they will be overwritten.
1. Go to Device Configuration > Extended Settings.
2. Check Overwritten Record to enable the function.
3. Click Save.
4. Reboot the device according to the prompt.
3.5.10 Set Vibration
Vibration is enabled by default to notify you of the device working status. You can disable the function.
1. Go to Device Configuration > Extended Settings.
2. Check or uncheck Vibration.
3. Click Save.
Result
If vibration is enabled, the device will vibrate under different conditions. See Quick Start Guide for details.
3.5.11 Enable Debug Mode
Debug mode is disabled by default. If you want to record the debug log, enable debug mode.
1. Go to Device Configuration > Extended Settings.
2. Check Debug Mode.
3. Click Save.
Result
Click Log Information to view the debug log.
3.6 Export File
You can export videos to your computer via assistant or USB mode.

HIKVISION DS-MCW405 Specifications

General

Maximum frame rate	25 fps
Maximum resolution	1920 x 1080 pixels
Minimum illumination	- lx
Housing color	Black
International Protection (IP) code	IP67
Internal memory	32 GB
Wi-Fi	Yes
Bluetooth	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Connectivity technology	Wireless
Storage temperature (T-T)	-20 - 55 °C
Power source type	Battery
Recording battery life	12 h

Weight and Dimensions

Depth	75 mm
Width	55 mm
Height	24 mm
