HIKVISION DS-PS1-I-WB - Signaling Test

112
 = Server Setting =
 Address Type
— IP
— Domain Name
 Server Address / Domain Name
 Port No.
Input IP address or domain name by which the transceiver of receiving center could be
reached. Input port number of the server provided by the ARC
 = Account Setting =
 Account Code
Input the assigned account provided by the ARC.
 = SIA DC-09 Protocol Setting =
 Transmission Mode
— TCP
— UDP
Both TCP and UDP are supported for transmission. UDP is recommended by the SIA DC-09
standard.
 Connection Setting
○ Impulse Counting Time / Retry Timeout Period
Setup the timeout period waiting for receiver to respond. Re-transmission will be
arranged if the transceiver of receiving center is timeout.
○ Attempts
Setup the maximum number that re-transmission will be tried.
○ Polling Rate
Setup the interval between 2 live polling if enable is checked.
 Encryption Setting
○ Encryption Arithmetic
— AES
○ Password Length
— 128
— 192
— 256
○ Secret Key
Setup the encryption key length and input the key provided by the ARC.
Signaling Test
Activate a panic alarm from the control panel.
