HIKVISION HWI-B120H-U User Manual

Network Camera User Manual
43
Note:
 VCA Resource function varies according to different camera models.
 VCA options are mutually exclusive.
 The function may not be supported by some camera models.
Operating PTZ Control
Purpose:
In the live view interface, you can use the PTZ control buttons to realize pan/tilt/zoom
control of the camera.
Note: To realize PTZ control, the camera connected to the network must support the
PTZ function or have a pan/tilt unit installed to the camera. Please properly set the
PTZ parameters on RS485 settings page referring to Section 6.2.4 RS485 Settings.
5.5.1 PTZ Control Panel
On the live view page, click next to the right side of the live view window to show
the PTZ control panel and click to hide it.
Click the direction buttons to control the pan/tilt movements.
PTZ Control Panel
Click the zoom/focus/iris buttons to realize lens control.
Notes:
 There are eight direction arrows ( , , , , , , , ) in the control
panel. Click the arrows to realize adjustment in the relative positions.

HIKVISION HWI-B120H-U Specifications

General

Brand	HIKVISION
Model	HWI-B120H-U
Category	Security Camera
Language	English
