HIKVISION iDS-TCV500-BI User Manual

Network Traffic Camera • User Manual
32
The video parameters vary according to different device models. Refer to the actual display page
for device functions.
Set Image Encoding
Go to Configuration >Device Configuration > Encoding and Storage > Image Encoding.
Image Encoding
Select Capture Resolution.
Enter JPEG Picture Size and Composite Picture Size. The captured pictures are saved as
JPEG files, and the size refers to max. size of each captured picture.
Click Save.
Set ROI
Purpose:
ROI (Region of Interest) encoding helps to discriminate the ROI and background information in
video compression, which means, the technology assigns more encoding resource to the region of
interest, thus to increase the quality of the ROI whereas the background information is less
focused.
ROI function varies according to different device models.

HIKVISION iDS-TCV500-BI Specifications

General

Card reader integrated	Yes
Maximum memory card size	128 GB
Maximum resolution	2464 x 2056 pixels
Image quality adjustment	Saturation, Brightness, Contrast, Sharpness, DNR
Video compression formats	H.264, H.265
Placement supported	Outdoor
Signal-to-Noise Ratio (SNR)	60 dB
Number of users	32 user(s)
Supported network protocols	TCP/IP, HTTP, HTTPS, FTP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, IPv6, UDP
Focus	Motorized/Manual
Minimum illumination	0.001 lx
Housing material	Aluminum
International Protection (IP) code	IP66
