HIKVISION iDS-TCV500-BI User Manual

Network Traffic Camera • User Manual
63
− Check Enable Detection Area to enable the vehicle capture triggered by video analysis. It
is recommended to draw the video detection area according to the actual
environment to avoid the false trigger.
6) Click OK to save the drawing and exit the drawing interface.
7) (Optional) Check Display All Areas to display all the LPR areas.
Select the linkage flash light output.
Usually one lane is linked to one flash light. If you link more than 1 flash light, you need to select
Flashlight Mode. Simultaneous flash and sequential flash are selectable.
(Optional) If you select Speed Detect Mode as Radar, set the radar settings.
(Optional) Copy the configuration of current lane to other lanes.
Click Save to save the settings.
You can click the Default button to restore the parameters to default values.
Video Analysis E-Police
Go to Configuration > Device Configuration > Application Mode, and select Application
Mode as Video Analysis E-police.
Set corresponding video analysis capture parameters.

HIKVISION iDS-TCV500-BI Specifications

General

Card reader integrated	Yes
Maximum memory card size	128 GB
Maximum resolution	2464 x 2056 pixels
Image quality adjustment	Saturation, Brightness, Contrast, Sharpness, DNR
Video compression formats	H.264, H.265
Placement supported	Outdoor
Signal-to-Noise Ratio (SNR)	60 dB
Number of users	32 user(s)
Supported network protocols	TCP/IP, HTTP, HTTPS, FTP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, IPv6, UDP
Focus	Motorized/Manual
Minimum illumination	0.001 lx
Housing material	Aluminum
International Protection (IP) code	IP66
