HIKVISION iDS-TCV500-BI User Manual

Network Traffic Camera • User Manual
50
Set Traffic Light Synchronization
Go to Configuration> Device Configuration > Capture Parameters > Traffic Light
Synchronization.
Set Traffic Light Synchronization
Check Enable Traffic Light Synchronization, to adjust the device phase position in sync.
with that of flash light.
Enter Phase Position to adjust flash light brightness. It ranges from 0 to 360.
Select Signal Frequency according to actual power supply frequency.
Click Save to save the settings.
Set Image Composition
A group of composed images can give direct evidence to the illegal driving actions. Set the image
composition on this page.
Go to Configuration> Device Configuration > Capture Parameters > Image Composition.
Image Composition
Check Enable Composition.
Select the composition method. Click the Option box, and select the composition method
from the pop-up dialog box.

HIKVISION iDS-TCV500-BI Specifications

General

Card reader integrated	Yes
Maximum memory card size	128 GB
Maximum resolution	2464 x 2056 pixels
Image quality adjustment	Saturation, Brightness, Contrast, Sharpness, DNR
Video compression formats	H.264, H.265
Placement supported	Outdoor
Signal-to-Noise Ratio (SNR)	60 dB
Number of users	32 user(s)
Supported network protocols	TCP/IP, HTTP, HTTPS, FTP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, IPv6, UDP
Focus	Motorized/Manual
Minimum illumination	0.001 lx
Housing material	Aluminum
International Protection (IP) code	IP66
