HIKVISION iDS-TCV500-BI User Manual

Network Traffic Camera • User Manual
75
5) Select Capture Interval type between time and distance, and set the interval time or
interval distance.
6) Set Speed Limit Sign according to actual speed value on speed restriction board, and
it will be overlaid on captured picture.
7) Set Speed Limit for Truck. When the truck speed exceeds the set speed limit, capture
will be triggered.
8) Set Min. Speed for Truck. When the truck speed exceeds the set min. speed, capture
will be triggered.
9) Select the linkage flash light output.
Usually one lane is linked to one flash light. If you link more than one flash light, you need to select
Flash light Mode. Simultaneous flash and sequential flash are selectable.
(Optional) Copy the configuration of current lane to other lanes.
Click Save to save the settings.
You can click the Default to restore the parameters to default values.
RS-485 Radar
If high accuracy speed detection is required, you can select the trigger mode as RS-485 Radar.
Go to Configuration > Device Configuration > Application Mode.
Select Application Mode as RS-485 Radar.

HIKVISION iDS-TCV500-BI Specifications

General

Card reader integrated	Yes
Maximum memory card size	128 GB
Maximum resolution	2464 x 2056 pixels
Image quality adjustment	Saturation, Brightness, Contrast, Sharpness, DNR
Video compression formats	H.264, H.265
Placement supported	Outdoor
Signal-to-Noise Ratio (SNR)	60 dB
Number of users	32 user(s)
Supported network protocols	TCP/IP, HTTP, HTTPS, FTP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, IPv6, UDP
Focus	Motorized/Manual
Minimum illumination	0.001 lx
Housing material	Aluminum
International Protection (IP) code	IP66
