HIKVISION iDS-TCV500-BI User Manual

Network Traffic Camera • User Manual
79
 Linkage 485 No.: Select the communication interface of radar.
 Sensitivity: Enter the sensitivity.
 Angle: Enter the angle of the radar and the horizontal direction according to the actual
application.
 Linearity Correction: You may need to adjust the radar output result according to the actual
speed.
 Constant Correction: In order to improve the accuracy of the detection speed, there is a
constant correction, which is the extra added/ minus speed value.
The final speed is the calculated according to the radar output speed, the linearity correction, and
constant correction together.
Example: The speed detected is 80km/h, and you set the linearity correction coefficient as 1.2, and
the constant correction as 5, then the final speed is 80km/h*1.2+5=101km/h. And if you do not
want to make any change to the detected speed, you can set the linearity correction coefficient as
1, and the constant correction as 0.
(Optional) Copy the configuration of current lane to other lanes.
Click Save to save the settings.
You can click the Default button to restore the parameters to default values.

HIKVISION iDS-TCV500-BI Specifications

General

Card reader integrated	Yes
Maximum memory card size	128 GB
Maximum resolution	2464 x 2056 pixels
Image quality adjustment	Saturation, Brightness, Contrast, Sharpness, DNR
Video compression formats	H.264, H.265
Placement supported	Outdoor
Signal-to-Noise Ratio (SNR)	60 dB
Number of users	32 user(s)
Supported network protocols	TCP/IP, HTTP, HTTPS, FTP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, IPv6, UDP
Focus	Motorized/Manual
Minimum illumination	0.001 lx
Housing material	Aluminum
International Protection (IP) code	IP66
