17
● Horizontal drilling with vacuum attachment is per-
missible only when an additional means of securing the
drill stand is employed. The drill stand may be used for
overhead drilling only when fastened by an anchor or
by means of a quick-release brace.
● Drilling into materials containing asbestos is not per-
missible.
● Changes or modifications to the tool are not permis-
sible.
● To avoid the risk of injury, use only original Hilti acces-
sories and additional equipment.
● Observe the information printed in the operating
instructions concerning operation, care and mainte-
nance.
3. Tools and accessories
Designation Item no.
Vacuum pump 47034
Quick-release brace 9870
Water collector system for hand-held use 370462
Water collector system for drill stand use 370460
Drill stand 370461
Wheel assembly 232228
DD-CS M12S-SM clamping spindle 251830
DD-CN SML clamping nut 251834
2. Description
The DD 130 is an electrically powered diamond core drilling machine designed for hand-held use or for mounting
on a drill stand. It is suitable for wet or dry core drilling.
Use as intended
The DD 130 is designed for drilling through holes and blind holes in mineral materials.
Applications:
With / without drill stand Core bit diameter Drilling direction
Hand-held / dry With dust extraction, 12–162 mm dia. All directions
Hand-held / wet Without water collection system, 12– 62 mm dia. Not upwards
Hand-held / wet With water collection system, 12– 62 mm dia. All directions
Drill stand / wet Without water collection system, 12–152 mm dia. Not upwards
Drill stand / wet With water collection system 12–132 mm dia. All directions
When drilling in an upwards direction, a wet-type vacuum cleaner must be connected to the water collection system.
● The tool is intended for professional use.
● The tool may be operated, serviced and repaired only
by authorised, trained personnel. This personnel must
be informed of any special hazards that may be encoun-
tered.
● The tool and its accessories may, nevertheless, pre-
sent hazards when used incorrectly by untrained per-
sonnel or when used not as directed.
Items supplied
The items supplied are: core drilling machine and oper-
ating instructions.
