4. Technical data
Nominal voltage: * 110 V 120 V 220 V 230 V 240 V
Nominal power: 1700 W 1800 W 1900 W 1900 W 1900 W
Nominal current: * 16 A 15 A 9.1 A 8.7 A 8.3 A
Frequency 50/60 Hz 50/60 Hz 50/60Hz 50/60Hz 50/60Hz
Nominal no-load speed 1
st
gear 780 r.p.m.
2
nd
gear 1400 r.p.m.
3
rd
gear 2600 r.p.m.
(Change gear only when rotation has stopped.)
Max. permissible water supply pressure: 6 bar (In the event of higher water pressure, a
pressure reduction valve must be fitted at the building
site connection.)
Dimensions (L×W×H): 515×114×170 mm
Weight as per EPTA-Procedure 01/2003: 7.3 kg
Radio and television interference suppression as per EN 55014-1
Interference immunity: as per EN 55014-2
Protection class as per EN 60745 and IEC 60745: Protection class I (earthed)
Drilling depth: max. 430 mm (730 mm with extension)
Noise and vibration information (measured in accordance with EN 60745):
Typical A-weighted noise power level (LwA): 100 dB (A)
Typical A-weighted noise emission pressure level (LpA): 89 dB (A)
For the given sound power level as per EN 60745, the tolerance is 3 dB.
Wear ear protection!
Triaxial vibration value (vibration vector sum) measured in accordance with EN 60745-2-1
Drilling into concrete, with water supply, (a
h, DD
): 5.0 m/s
2
Drilling into sand-lime-stone, dry, (a
h, DD
): 6.0 m/s
2
Uncertainty (K) for triaxial vibration value: 1.5 m/s
2
Information for the user in accordance with EN 61000-3-11:
Switching on the tool may cause a brief voltage drop. Under unfavourable conditions in the mains supply, this
may cause interference to other appliances. No interference is to be expected when the mains supply has an
impedance of < 0.15 ohms.
* The tool is available in versions for various nominal voltages. Please refer to the rating plate for information on
the nominal voltage and nominal current rating of the applicable tool.
Right of technical changes reserved
5. Safety rules
5.1 General safety rules
-WARNING- Read all instructions!
Failure to follow all
instructions listed below may result in electric shock,
fire and/or serious injury. The term "power tool" in all of
the warnings listed below refers to your mains operat-
ed (corded) power tool or battery operated (cordless)
power tool.
SAVE THESE INSTRUCTIONS
5.1.1 Work area
a) Keep the work area clean and well lit.
Cluttered and
dark areas invite accidents.
b) Do not operate power tools in explosive atmos-
pheres, such as in the presence of flammable liq-
uids, gases or dust.
Power tools create sparks which
may ignite the dust or fumes.
c)Keep children and bystanders away while operat-
ing a power tool.
Distractions can cause you to lose
control.
5.1.2 Electrical safety
a) Power tool plugs must match the outlet. Never mod-
ify the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools.
Unmodified
plugs and matching outlets will reduce risk of elec-
tric shock.
b) Avoid body contact with earthed or grounded sur-
faces such as pipes, radiators, ranges and refrig-
erators.
There is an increased risk of electric shock
if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.
To Next Page
