8 English 2153083
*2153083*
4.2 Technical data for the floor saw
Further data not listed here corresponds to the data for the electric wall saw used
and can be found in the operating instructions for the applicable wall saw.
Suitable saws
•
DST 10CA electric wall
saw
•
DST 10E electric wall
saw
Suitable blade guard types
•
DSBG65 saw blade
guard
•
DSTBG80 saw blade
guard
Saw blade diameter (when using the DSF 1030TS
trolley)
600 mm … 800 mm
Maximum cutting depth
33 cm
Total vibration (a
h
)
< 2.5 m/s²
Measured in
accordance with
EN 13862:2001+A1:2009
5 Preparations at the workplace
5.1 Preparing the floor saw trolley for mounting the saw
WARNING
Risk of accident! The drive wheels cannot be locked when no saw head is mounted on
the trolley. There is thus a risk of the floor saw trolley running away on a slope.
▶ Always position the floor saw trolley on a horizontal surface before assembly or
disassembly.
Printed: 07.05.2019 | Doc-Nr: PUB / 5492449 / 000 / 00
