TOOL ANATOMY
4
INDEX
Handle
Trigger Button
Cartridge Outlet
Nail Release Button
Magazine Guide
Carrying Handle
Stop
Nail Magazine
Pressure Pin
Magazine Release Button
Cartridge Inlet
Housing
Cartridge Channel
Pawl
Rotating Sleeve
Nail Detection Mechanism
