8 English 2235450
*2235450*
Electrical safety
▶ Before beginning work, check the working area for concealed electric
cables or gas and water pipes. External metal parts of the power tool may
give you an electric shock if you damage an electric cable accidentally.
Power tool use and care
▶ Secure the workpiece. Use clamps or a vice to hold the workpiece in
position. The workpiece is thus held more securely than by hand and both
hands remain free to operate the power tool.
▶ Immediately switch off the power tool if the accessory tool jams. The
power tool might twist off-line.
▶ Wait until the power tool stops completely before you lay it down.
3 Description
3.1 Product overview 1
@
Keyless chuck
;
Torque setting ring
=
Function setting ring
(only SF 2H A)
%
Gear selector switch
&
Forward/reverse selector
switch with safety lock
(
Grip
)
LED light
+
Belt hook (optional)
§
Battery state of charge indica-
tor
/
Battery release button
:
Control switch with speed
control
3.2 Intended use
The product described is a hand-held cordless drill / driver for driving and
removing screws, drilling in metal, wood and plastic.
▶ Use only Hilti Liion batteries of the B 12 series with this product.
▶ Use only Hilti battery chargers of the C4/12 series for charging these
batteries.
3.3 Charge status display
The charge status of the Liion battery is displayed after pressing the release
button.
Status Meaning
4 LEDs light. Charge status: 75 % to 100 %
3 LEDs light. Charge status: 50 % to 75 %
2 LEDs light. Charge status: 25 % to 50 %
1 LED lights. Charge status: 10 % to 25 %
1 LED blinks. Charge status: < 10 %
Printed: 19.09.2019 | Doc-Nr: PUB / 5509387 / 000 / 01
