6 English 2253585
*2253585*
4 Technical data
Rated voltage
21.6 V
Stroke rate at idle speed
1,185 /min … 2,680 /min
Weight in accordance with EPTA Procedure 01 including B22⁄8.0
battery
3.3 kg
Ambient temperature for operation
−17 ℃ … 60 ℃
Storage temperature
−20 ℃ … 70 ℃
4.1 Battery
Battery operating voltage
21.6 V
Ambient temperature for operation
−17 ℃ … 60 ℃
Storage temperature
−20 ℃ … 40 ℃
Battery charging starting temperature
−10 ℃ … 45 ℃
4.2 Noise information and vibration values in accordance with EN 62841
The sound pressure and vibration values given in these instructions were measured in accordance with a
standardized test and can be used to compare one power tool with another. They can also be used for a
preliminary assessment of exposure.
The data given represent the main applications of the power tool. However, if the power tool is used for
different applications, with different accessory tools, or is poorly maintained, the data can vary. This can
significantly increase exposure over the total working period.
An accurate estimation of exposure should also take into account the times when the tool is switched off, or
when it is running but not actually being used for a job. This can significantly reduce exposure over the total
working period.
Identify additional safety measures to protect the operator from the effects of noise and/or vibration, for
example: maintaining the power tool and accessory tools, keeping the hands warm, organization of work
patterns.
Noise information
Typical A-weighted sound power level (L
WA
)
89 dB(A)
Uncertainty for the sound power level (K
WA
)
3 dB(A)
Typical A-weighted emission sound pressure level (L
pA
)
78 dB(A)
Uncertainty for the sound pressure level (K
pA
)
3 dB(A)
Vibration information
Triaxial vibration value (a
h
)
3.8 m/s²
Uncertainty (K)
1.5 m/s²
4.3 Blade
Blades of different types are needed, depending on the thickness or strength of the material to be cut. Select
the correct blade for the purpose from the table below.
The blades have two cutting edges. The cutting edges cannot be resharpened.
Initial equipment, as supplied ex works: SSHCS 1.5 2.5 mm
