Hilti TE 2-A22 Operating Instructions

*2023934*
2023934 English 7
5.1.1 Fitting the side handle 4
1. Release the side handle clamping band by turning the handle grip.
2. Slide the side handle clamping band over the chuck from the front and into the recess provided.
3. Bring the side handle into the desired position.
4. Tighten the side handle clamping band by turning the handle grip.
5.1.2 Inserting the battery 2
1. Push the battery into the battery interface on the tool until it is heard to engage with a click.
2. Check that the battery is seated securely.
5.1.3 Removing the battery 3
1. Press the release buttons on the battery.
2. Pull the battery out toward the rear.
5.1.4 Fitting the accessory tool 5
1. Apply a little grease to the connection end of the accessory tool.
▶ Use only the recommended grease supplied by Hilti. Use of the wrong grease can result in damage
to the tool.
2. Push the accessory tool into the chuck as far as it will go (until it engages).
3. After fitting the accessory tool, grip it and pull it in order to check that it is securely engaged.
▶ The product is ready for use.
5.1.5 Removing the accessory tool 6
WARNING
Risk of injury! The tool becomes hot as a result of use.
▶ Wear protective gloves when changing the tool.
▶ Pull the chuck back as far as it will go and remove the accessory tool.
5.1.6 Fitting the depth gauge (optional) 7
1. Release the side handle clamping band by turning the handle grip.
2. Slide the depth gauge from the front into the 2 guide holes provided.
3. Tighten the side handle clamping band by turning the handle grip.
5.2 Types of work
ATTENTION
Risk of damage by incorrect handling!
▶ Do not operate the switches for direction of rotation and/or function selection during operation.
Observe the safety instructions and warnings in this documentation and on the product.
5.2.1 Lighting in the workplace
The LED is activated automatically when the control switch is pressed. The LED goes out slowly after
the control switch is released.
▶ Press the control switch.
5.2.2 Direction of rotation
▶ Set the direction of rotation.
▶ The selector switch engages in this position.
5.2.3 Drilling without hammering 8
▶
Set the function selector switch to this symbol: .
5.2.4 Hammer drilling 8
▶
Set the function selector switch to this symbol: .

Hilti TE 2-A22 Specifications

General

Power source	Battery
Battery voltage	21.6 V
Impact rate	5040 bpm
Rated speed (max)	1090 RPM
Impact energy (max)	1.5 J
Vibration level (hammer drilling)	15 m/s²
Product color	Black, Red
Built-in light	Yes
Noise level	92 dB

Weight and Dimensions

Weight	2700 g
