Hilti TE 50-AVR User Manual

English 1
1 Information about the documentation
1.1 About this documentation
• Read this documentation before initial operation or use. This is a
prerequisite for safe, trouble-free handling and use of the product.
• Observe the safety instructions and warnings in this documentation and
on the product.
• Always keep the operating instructions with the product and make sure
that the operating instructions are with the product when it is given to
other persons.
1.2 Explanation of symbols used
1.2.1 Warnings
Warnings alert persons to hazards that occur when handling or using the
product. The following signal words are used:
DANGER
DANGER !
▶ Draws attention to imminent danger that will lead to serious personal
injury or fatality.
WARNING
WARNING !
▶ Draws attention to a potential threat of danger that can lead to serious
injury or fatality.
CAUTION
CAUTION !
▶ Draws attention to a potentially dangerous situation that could lead to
slight personal injury or damage to the equipment or other property.
1.2.2 Symbols in the documentation
The following symbols are used in this document:
Read the operating instructions before use.
Instructions for use and other useful information
Dealing with recyclable materials
Do not dispose of electric equipment and batteries as household
waste
1.2.3 Symbols in the illustrations
The following symbols are used in illustrations:
Printed: 14.12.2018 | Doc-Nr: PUB / 5283568 / 000 / 03

Hilti TE 50-AVR Specifications

General

Drilling	Yes
Chuck type	SDS Max
Product color	Black, Red
Country of origin	Germany
Impact rate	3180 bpm
Rated speed (max)	360 RPM
Impact energy (max)	6 J
Vibration level (hammer drilling)	9 m/s²
Drilling diameter in concrete (max)	40 mm
Optimum drilling diameter (concrete)	16 - 32 mm
Input power	1100 W
Power source	AC
Power plug type	Type C
Noise level	108 dB
Quantity per shipping (inner) case	1 pc(s)

Weight and Dimensions

Weight	6100 g
Package depth	3456 mm
Package width	2000 mm
Package height	4500 mm
Package weight	4500 g
