It is essential that the operating instructions
are read before the tool is operated for the
first time.
Always keep these operating instructions
together with the tool.
Ensure that the operating instructions are
with the tool when it is given to other
persons.
TE 706/TE 706-AVR breaker
1. General information
1.1 Safety notices and their meaning
-CAUTION-
Draws attention to a potentially dangerous situation that
could lead to minor personal injury or damage to the
equipment or other property.
-NOTE-
Draws attention to instructions and other useful infor-
mation.
1.2 Pictograms
Contents Page
1. General information 11
2. Description 12
3. Tools and accessories 12
4. Technical data 13
5. Safety rules 13
6. Before use 15
7. Operation 15
8. Care and maintenance 16
9. Troubleshooting 17
10. Disposal 18
11. Manufacturer’s warranty – tools 18
12. EC declaration of conformity 19
Operating controls and parts
Chuck
Chisel adjustment and locking switch
On/off switch
Grip
Supply cord
Screw knob
Side handle
Lock symbol
Power level selection switch
Theft protection indicator (option)
Service indicator
These numbers refer to the corresponding illustra-
tions. The illustrations can be found on the fold-out cover
pages. Keep these pages open while studying the oper-
ating instructions.
In these operating instructions, the TE 706 and / or
TE 706-AVR breaker is referred to as “ the power tool”.
Location of identification data on the power tool.
The type designation can be found on the rating plate
and the serial number on the side of the motor housing.
Make a note of this data in your operating instructions
and always refer to it when making an enquiry to your
Hilti representative or service department.
Type:
Serial No.:
Warning signs
Symbols
General
warning
Warning:
electricity
Warning:
hot surface
Read the
operating
instructions
before use.
Return waste
material for
recycling
Lock-
symbol
Equipped with
theft protection
system
