2. Description
2.1 Use of the power tool as intended
The power tool is designed for medium-duty chiseling
work. It is suitable for breaking/removing and demol-
ishing concrete, masonry, stone or asphalt. It is intended
for use on construction sites of all kinds.
The power tool may be operated only when connected
to a power supply providing a voltage and frequency in
compliance with the information given on its rating plate.
Changes or modifications to the power tool are not per-
missible.
2.2 Important features of the power tool
2.2.1 Active vibration reduction
● The TE 706-AVR is equipped with an active vibration
reduction system which cuts vibration to 40% of that
of the TE 706 (without Active Vibration Reduction).
2.2.2 Theft protection system (option)
● The power tool may be equipped with the optional
theft protection system. If the power tool is equipped
with this feature, it can be activated and made ready
for operation only by way of the corresponding acti-
vation key.
2.2.3 Chuck
● TE-Y (SDSmax) quick-change chuck
2.2.4 Switch
● On/off switch
● 3-position power level selection switch (100%, 75%,
50%)
● Chisel adjustment and locking switch (for 24 click-
stop positions per revolution)
3. Tools and accessories
TE 706/TE 706-AVR
TE-Y chuck (SDSmax)
Pointed chisel
Flat chisel
Wide-flat chisel
Hollow chisel
Channel chisel
Mortar chisel
Flexible chisel
Bushing tool
Tamping tool
Earth rod rammer
TPS Theft Protection System with Company
Card, Company Remote and TPS-K activation key
Use the Hilti tools listed above. With these tools you will achieve a higher breaking and material removal
performance and longer service life as the power tool and the insert tool have been optimized as a system.
2.2.5 Grip (with soft synthetic rubber padding)
● Two-way adjustable (pivoting) and vibration-absorb-
ing side handle
● Vibration absorbing grip
2.2.6 Safety features
● Electronic interlock to prevent unintentional restart-
ing after interruption of the power supply (see sec-
tion 9.).
● Casing and grip isolated from interior parts of the tool
to reduce transmission of heat and vibration.
● Automatic electronic overheating and overvoltage cut-
out (see section 9.).
2.2.7 Lubrication
● Permanent lubrication with separate lubrication cham-
bers for the gearing section and hammering mecha-
nism.
2.2.8 Indicator lamps
● Service indicator lamp (red, see section 8.3).
● Theft protection system indicator (available as an
option) (yellow, see section 7.2.1).
2.2.9 Items supplied as standard
● Power tool
● Side handle
● Grease dispenser, 50 ml
● Cleaning cloth
● Operating instructions
● Toolbox complete with overview of the insert tools
(chisels) available.
Width (mm)
– –
26
50–120
28
22–36
38
150
40 x 40
150 x 150
∅ 15–25
option
Length (mm)
280–700
280–700
280–500
280
280
280
650
250
300
300
Width (in)
– –
3
/4″
2″–4
1
/2″
1″
7
/8″–1
1
/2″
15
/16″
5
7
/8″
5
7
/8″
– –
– –
Length (in)
11″–27″
11″–27″
11″–19″
11″
11″
11″
25
1
/2″
10″
– –
– –
