X-DO 32 01 3 Product Description
HI 801 097 E Rev. 4.00 Page 19 of 52
3.6 Connector Boards
A connector board connects the module to the field zone. Module and connector board
form together a functional unit. Insert the connector board into the appropriate slot prior to
mounting the module.
The following connector boards are available for the module:
Designation Description
X-CB 009 01 Connector board with screw terminals
X-CB 009 02 Redundant connector board with screw terminals
X-CB 009 03 Connector board with cable plug
X-CB 009 04 Redundant connector board with cable plug
Table 9: Available Connector Boards
3.6.1 Mechanical Coding of Connector Boards
I/O modules and connector boards are mechanically coded starting from hardware revision
AS10 to prevent them from being equipped with improper I/O modules. Coding avoids
incorrect installation of improper I/O modules thus preventing negative effects on redundant
modules and field zone. A part from that, improper equipment has no effect on the HIMax
system since only I/O modules that are correctly configured in SILworX enter the RUN
state.
I/O modules and the corresponding connector boards have a mechanical coding in form of
wedges. The coding wedges in the female connector of the connector board match with the
male connector recesses of the I/O module plug, see
Figure 5.
Coded I/O modules can only be plugged in to the corresponding connector boards.

HIMA HIMax X-DO 32 01 Specifications

General

Product type	Digital Output Module
Number of channels	32
Rated voltage	24 V DC
Current per channel	0.5 A
Short-circuit protection	Yes
Galvanic isolation	Yes
Protection class	IP20
Connection type	Screw terminal
