HIMA HIMax X-DO 32 01 User Manual

X-DO 32 01 3 Product Description
HI 801 097 E Rev. 4.00 Page 25 of 52
3.6.6 Pin Assignment for Connector Boards with Cable Plug
HIMA provides ready-made system cables for use with these connector boards, see
Chapter
3.7. The cable plug and the connector boards are coded.
i
Connector pin assignment!
The following table describes the connector pin assignment of the system cable plug.
Lead marking based on DIN 47100:
c b a
Row
Signal Color Signal Color Signal Color
1 DO32+ PK-BN
1)
DO32- WH-PK
1)
Reserved YE
2)
2 DO31+ GY-BN
1)
DO31- WH-GY
1)
Reserved GN
2)
3 DO30+ YE-BN
1)
DO30- WH-YE
1)
Reserved BN
2)
4 DO29+ BN-GN
1)
DO29- WH-GN
1)
Reserved WH
2)
5 DO28+ RD-BU
1)
DO28- GY-PK
1)
6 DO27+ VT
1)
DO27- BK
1)
7 DO26+ RD
1)
DO26- BU
1)
8 DO25+ PK
1)
DO25- GY
1)
9 DO24+ YE
1)
DO24- GN
1)
10 DO23+ BN
1)
DO23- WH
1)
11 DO22+ RD-BK DO22- BU-BK
12 DO21+ PK-BK DO21- GY-BK
13 DO20+ PK-RD DO20- GY-RD
14 DO19+ PK-BU DO19- GY-BU
15 DO18+ YE-BK DO18- GN-BK
16 DO17+ YE-RD DO17- GN-RD
17 DO16+ YE-BU DO16- GN-BU
18 DO15+ YE-PK DO15- PK-GN
19 DO14+ YE-GY DO14- GY-GN
20 DO13+ BN-BK DO13- WH-BK
21 DO12+ BN-RD DO12- WH-RD
22 DO11+ BN-BU DO11- WH-BU
23 DO10+ PK-BN DO10- WH-PK
24 DO9+ GY-BN DO9- WH-GY
25 DO8+ YE-BN DO8- WH-YE
26 DO7+ BN-GN DO7- WH-GN
27 DO6+ RD-BU DO6- GY-PK
28 DO5+ VT DO5- BK
29 DO4+ RD DO4- BU
30 DO3+ PK DO3- GY
31 DO2+ YE DO2- GN
32 DO1+ BN DO1- WH
1)
Additional orange ring if one lead marking color is repeated.
2)
Additional violet ring if one lead marking color is repeated for the second time.
Table 13: Pin Assignment for the System Cable Plug
