(APPENDIX I) PARAMETERS TABLE | PAGE 33
Tabla 3
Regulations table
Psw
Description
Default
value
Range
2
2
Default Starting Mode.
1
0- Locked
1- Manual
2- Automatic
3- Test
11
2
Con guration of the PEM input.
2
0- OFF
1- Normally open
2- Normally closed
12
2
Con guration of the ENT1 input.
1
13
2
Con guration of the ENT2 input.
1
14
2
Con guration of the ENT3 input.
1
23
2
Voltage transformer.
0
0- Not installed
1- Transformer 400/600
24
2
Position of current measured.
0
0- Unit panel
1- Output line
2- Network line
30
2
Selection of control unit type.
0
0- Switching in integrated
mode
2- Switching in external
mode
3- Switching in external
smart mode
31
2
Genset in reserve.
0
0- Disabled
4- Enabled
NOTE
After modifying parameter 30 the control unit must be reset by disconnecting its
power, to allow the updating of its operating mode.
Tabla 1
Times table
Parameter
Psw
Description
Default
value
Range
3
2
Start Delay.
Time between power failure and engine start.
0’
0’’..1800’
6
2
Charging Activation Time.
Time from the moment the starting of the engine is
detected until the activation of the genset contactor.
3’
1’’..600’
7
2
Nominal condition time.
Time from the moment the starting of the engine
is detected until the quality of the signal generated
begins to be validated.
2”
2”..15”
10
2
Delay Network Activation.
Time elapsed between correct network signal and
switching of contactors.
60’
1”’..600’”
11
2
Cooling Time.
120’
2’’..1800’
13
2
Time from detection of contactor activation con r-
mation.
5”
1’’..3000’
14
2
Maximum alarm activation time.
The alarm output is activated (together with the
ashing of the reset and buzzer LED on the display)
when appropriate during this time limit.
15”
0- Inde nite
1”..1800”
22
2
Filtering of the ENT1 input.
1,0’
0,0’’..120,0’
23
2
Filtering of the ENT2 input.
1,0’
0,0’’..120,0’
24
2
Filtering of the ENT3 input.
1,0’
0,0’’..120,0’
27
2
Load starting power detection time.
5’
1’’..3000’
35
2
Delay time between the activation of genset and grid
breakers.
2”
1’...250”
Tabla 2
Measurements table
Parameter
Psw
Description
Default
value
Range
1
2
Conversion factor of current transformers - Factor
common to RMS current values IR, IS, IT.
100
