Himoinsa CEC7 - Thresholds table; Alarms table

(APPENDIX I) PARAMETERS TABLE | PAGE 34
Parameter
Psw
Description
Default value
Range
37
Management unit commutation alarm 5
Maximum Unit Frequency alarm.
4
0..4
38
2
Filter unit commutation alarm 5
Maximum Unit Frequency alarm.
1
0”…30”
40
Management unit commutation alarm 6
Phase sequence alarm.
4
0..4
41
2
Filter unit commutation alarm 6
Phase sequence alarm.
8
0”…30”
61
Management unit commutation alarm 2
Minimum Unit Voltage alarm.
3
0..4
62
2
Filter unit commutation alarm 2
Minimum Unit Voltage alarm.
8
0”…30”
64
Management unit commutation alarm 4
Minimum Unit Voltage alarm.
3
0..4
65
2
Filter unit commutation alarm 4
Minimum Unit Voltage alarm.
8
0”…30”
71
2
Enable detection Unit Alarm
Unit stop failure.
3
0- Disabled
X- Enabled
76
2
Management unit commutation alarm 7
Unit voltage drop alarm.
3
0..4
77
2
Filter unit commutation alarm 7
Unit voltage drop alarm.
2
0”…30”
88
2
Management alarm C1
Maximum NETWORK voltage failure.
1
0..1
0. Not checked
1. Checked and if an
error is detected the
genset is started
89
2
Filter alarm C1.
5’’
0”…30”
90
2
Management alarm C2.
Minimum NETWORK voltage failure.
1
0..1
91
2
Filter alarm C2.
5’’
0”…30”
92
2
Management alarm C3.
Maximum NETWORK frequency failure.
1
0..1
93
2
Filter alarm C3.
5’’
0”…30”
94
2
Management alarm C4.
Minimum NETWORK frequency failure.
1
0..1
95
2
Filter alarm C4.
5’’
0”…30”
96
2
Management alarm C5.
Network sequence failure.
1
0..1
97
2
Filter alarm C5.
5’’
0”…30”
98
2
Management alarm C6.
Network signal drop failure.
1
0..1
99
2
Filter alarm C6.
5’’
0”…30”
100
2
Management alarm C7
CR commutation failure.
1
0. Not checked
1. Checked and if an
error is detected the
genset is started
Tabla 4
Thresholds table
Parameter
Psw
Description
Default
value
Range
1
2
Three-phase, two-phase, single phase or three-
phase without neutral, delta or delta without
neutral.
1
0- Three-phase
without
neutral
1- Three-phase
2- Two-phase
3- Single-phase
4- Delta
5- Delta without
neutral
6- Two-phase
selector
2
2
Maximum Unit Voltage.
440V
3
2
Minimum Unit Voltage.
360V
4
2
Maximum asymmetry value of the genset.
80V
5
2
Maximum Unit Frequency.
58Hz
6
2
Minimum Unit Frequency.
45Hz
13
2
Maximum NETWORK voltage.
440V
14
2
Minimum NETWORK voltage.
360V
15
2
Maximum NETWORK frequency.
55Hz
16
2
Minimum NETWORK frequency.
45Hz
20
2
Starting voltage in the genset signal.
40V
30-100
34
2
Starting activation power by
load demand.
0KW
0: Disabled
1...10000
35
2
Starting deactivation power by load demand.
0KW
0: Disabled
1...10000
Tabla 5
Alarms table
Parameter
Psw
Description
Default value
Range
31
Management unit commutation alarm 1
Asymmetric Alarm.
3
0- Not checked
1- Always checked
2- When starting
3- From start-
up condition (in
operation)
4- From nominal
condition (Stabilized)
32
2
Filter unit commutation alarm 1
Asymmetric Alarm.
8
0”…30”
34
Management unit commutation alarm 3
Maximum Unit Voltage alarm.
3
0..4
35
2
Filter unit commutation alarm 3
Maximum Unit Voltage alarm.
5
0”…30”
