Himoinsa CEC7 User Manual

(APPENDIX I) PARAMETERS TABLE | PAGE 35
Parameter
Psw
Description
Default value
Range
7
2
Maximum synchronisation wait time.
60
0..300”
8
2
Synch alarm action.
0
0- does not allow
power failure
1- allows power
failure
9
2
Power transfer threshold.
10
0- Disabled
10..90%
10
2
Active power balance factor.
10
10..500
11
2
Reactive power balance factor.
10
0- Disabled
1..200
Tabla 8
CC2 PROGRAMMING I/O table. External switching control unit mode
Parameter
Psw
Description
Default value
Range
1
3
Input associated to
programmable warning 2.
0
0- Alarm inhibited
1..4- SZ7 digital input
2
3
Polarity input to programmable
warning 2.
1
0- Low state active
1- High state active
3
3
Input associated to
programmable warning 3.
0
0- Alarm inhibited
1..4- SZ7 digital input
4
3
Polarity input associated to
programmable warning 3.
1
0- Low state active
1- High state active
5
3
Input associated to programma-
ble warning 4.
0
0- Alarm inhibited
1..4- SZ7 digital input
6
3
Polarity input associated to
programmable warning 4.
1
0- Low state active
1- High state active
7
3
Input associated to
programmable warning 5 .
0
0- Alarm inhibited
1..4- SZ7 digital input
8
3
Polarity input associated to
programmable warning 5.
1
0- Low state active
1- High state active
Tabla 9
Screen Table
Parameter
Psw
Description
Default value
Range
1
3
Inhibition of buzzer.
0
0: Buzzer enabled
1: Buzzer disabled
2
-
Reserved.
0
3
-
Enabling heating of display
(read-only parameter version DGT
version 4.45 or higher).
-
0: Disabled heating of display
1: Enabled heating of display
4..8
-
Reserved.
-
Parameter
Psw
Description
Default value
Range
102
2
Management alarm C8
CR commutation failure.
1
0. Not checked
1. Checked and if an
error is detected the
genset is stopped with
cooling
104
2
Filter unit commutation alarm 1
Asymmetric Alarm.
2
0- Not for genset
1- Stop genset
2- Stop engine with
cooling
3- Open genset
breaker
105
2
Unit commutation alarm 2 mode
Minimum Unit Voltage alarm.
2
106
2
Unit commutation alarm 3 mode
Maximum Unit Voltage alarm.
1
107
2
Unit commutation alarm 4 mode
Minimum Unit Voltage alarm.
2
108
2
Unit commutation alarm 5 mode
Maximum Unit Frequency alarm.
1
109
2
Unit commutation alarm 6 mode
Phase sequence alarm.
2
110
2
Unit commutation alarm 7 mode
Unit voltage drop alarm.
2
Tabla 6
Programming table (I/O)
Parameter
Psw
Description
Default value
Range
5
2
Input associated to CKR mode.
0
0- Not programmed
8- ENT1
9- ENT2
10- ENT3
6
2
Input associated to CKG mode.
0
8
2
Input associated to Enable mode in unit
contactor.
0
Tabla 7
Synchronization table
Parameter
Psw
Description
Default value
Range
1
2
Synch enable.
0
0- Disabled
1- Enabled
2- Enabled with
neutral switching
2
2
Amplitude synchronisation threshold.
3
0..20 V
3
2
Phase synchronisation threshold/frequency..
5
0..100 ‰
4
2
Amplitude adjustment time.
2
0..10 s
5
2
Frequency adjustment time.
10
0..10 network
periods
6
2
Duration of 2 contactors activated simulta-
neously.
6
0..10” PHR v2.60
or lower
60
0..100ds PHR v2.61
