(APPENDIX II) CONTROL UNIT SCREENS | PAGE 40
11.2 CONTROL UNIT MAINTENANCE
11.2.1. PASSWORD ENTRY
With the control unit connected, select "Menu" and press ü. To enter the
password using the cursor keys (+) and (-), select the number of the rst digit and
press ü. Use the same procedure with the 4 digits.
* * * * * * * MENU * * * * * * *
Password
0 0 0 0
11.2.2. MAIN MENU
The main menu screen gives access to the different menus, to enter each menu
select it with the cursor •▼and press ü:
1. Inputs/Outputs.
2. Parameters (only with authorization key).
3. Counters.
4. List of previous errors.
5. Schedule.
6. Date / Time.
7. Language Selection.
8. Customizing passwords.
9. Maintenance of electronic engine (ECU J1939).
10. Second zero maintenance (network/genset synchronization).
11. Harmonic analysis.
* * * * * * * MENU * * * * * * *
à
1 . Inputs/Outputs
2 . Parameters
q
3 . Counters
* * * * * * * MENU * * * * * * *
à
4 . History
p
5 . Schedule
q
6 . Date / Time
* * * * * * * M E N U * * * * * * *
à
7 . Language
p
8 . P a s s w o r d
q
9 . J 1 9 3 9
* * * * * * * MENU * * * * * * *
à
1 0 . Synchronization
p
1 1 . Harmonics
q
1. INPUTS AND OUTPUTS DISPLAY
* INPUTS/OUTPUTS *
3 2 1 0 9 8 7 6 5 4 3 2 1
I N : - - - 3 2 1 P - - - - - -
O U T : - - - - L g r - - - - - -
P: Emergency stop.
L: Free voltage contact start.
1: Programmable input 1.
2: Programmable input 2.
g: Genset contactor.
3: Programmable input 3.
r: Network contactor.
* ANALOGUE INPUTS
N C 0 . 0 P A 0 . 0
T M 0 . 0 A A 0 . 0
D I 0 . 0 V V B 0 . 0 V
NC: Fuel level.
PA: Oil pressure.
TM: Engine temperature.
AA: Auxiliary analogue.
DI: Alternator voltage.
VB: Battery voltage.
