OPERATING MODES | PAGE 14
4. OPERATING MODES
4.1 RECOMMENDATIONS
This series of recommendations is intended to ensure the optimum operation of
the control unit:
• Before you turn the control unit on, make sure that the supply
terminals are connected correctly and that the mode selection key is
in the "STOP" position.
• The control unit detects that the engine has started in two different
ways: by reading the frequency and by reading the battery charge
alternator voltage (D+). By default the control unit always detects the
engine has started by reading the frequency. If you want it to detect it
by reading the voltage on the D+ as well, you have to activate it using
microswitch 6 (SW6) (see section 3.3).
• The engine started detection by frequency can be performed in two
different ways: by Generator set or by Pick-Up. You cannot use both
simultaneously. The selection is carried out using microswitch 2, as
indicated in section 3.3.
• If you installed the Pick-Up in its corresponding terminals, you must
make sure that the terminals that correspond to the generator set
are disconnected and vice versa.
IMPORTANT
You cannot connect the generator set and the Pick-Up to the terminals of the
control unit at the same time under any circumstances.
• Make sure that the cable that activates the shutdown of the genset
is connected to the correct terminal of the control unit.
