Himunication HM390 - Connection Cables

6
Connection cables The details please check the below table
Serial
Number
General Description
Function Description
Different Color Code of the cable wires
(1)
RF antenna connector SMA
(Female)
VHF antenna
-
-
(2)
Red & Black Power
Power supply wires
Red
Power+ +13.8V
(3)
Black
Power- GND
(4)
Audio Connector
RCA (Phone) Plug
Hailer/Fog
White
SPK+
Black
SPK-
(5)
Audio Connector Black 3.5
mm Plug
External Speaker
Red
AUDIO-OUT
Black
GND
-
NC
(6)
NMEA 2000 connector
NMEA2000 network
Black
CANH
Red
CANL
(7)
NMEA 0183 connector
NMEA0183 network
Software upgrade
Green
USB-TX
Brown
0183_OUT
White
NC
Orange
0183_IN
Red
USB-RX
BARE WIRE
GND
Black
GND
(8)
EXT GPS ANT connector
EXT GPS ANT
-
-
(9)
GND connection hole
Grounding ware
-
-
(10)
Remote command
microphone connector
(Optional)
Remote command microphone
(Optional)
-
-
Connection cables in a package box
NMEA0183 connection cable, 0.4 m length (depending on a model)
Hailer cable, 0.4 m length
