Hioki 3283 - Chapter 5 Specifications; Measurement Specifications (23℃±5℃, 80% RH Max.); AC Current Arms (True Rms Indication)

29
Chapter 5 Specifications
Current Range
(Accuracy Range)
Resolution
Accuracy
(NOTE)
±(%rdg.+dgt.)
Maximum
permitted
current
10 mA
(1.00 to 10.00 mA)
0.01 mA
45 to 66 Hz:
±(1.0%+5)
40 to 45,
66 to 2 kHz:
±(2%+5)
20 A
AC rms,
continuous
(see fig. A)
100 mA
(10.0 to 100.0 mA)
0.1 mA
1A
(0.100 to 1.000 A)
0.001 A
10 A
(1.00 to 10.00 A)
0.01 A
200 A
(10.0 to 200.0 A)
0.1 A
45 to 66 Hz:
±(1.5%+5)
40 to 45,
66 to 2 kHz:
±(2.0%+5)
200 A
AC rms,
continuous
(see fig. A)
NOTE
Chapter 5
Specifications
5.1 Measurement Specifications
(23℃
℃℃
℃±
±±
±5℃
℃℃
℃, 80% RH max.)
5.1.1 AC current Arms (true rms indication)
･
Accuracy is for filter OFF.
･
Accuracy is for filter ON.
10 mA Range to 10 A Range:
50 Hz to 60 Hz (1.5%+5)
200ARange:50Hzto60Hz(2.0%+5)
