Chapter 2 Measurement Procedure
REC (recording output)
→
MON(waveform output)
→
out
(auto power-off disabled) (auto power-off disabled) (auto power-off enabled)
2.10 Output Function OUTPUT
An output signal corresponding to the
measured value can be obtained from the
unit. The output voltage (AC/DC) normally is
1 V for the full-scale count (1000). In the 200
A range, the output voltage (AC/DC) is 2 V
for the full-scale count (2000). The output
type is indicated by the
REC
(recording
output, DC) or
MON
(waveform output, AC)
indication.
1. Press the
RANGE
key to set the current
range to a fixed setting.
2. Press the
OUTPUT
key so that the
REC
indication appears. The output function is
now active.
Auto power-off is disabled. (The
APS
indication goes out.)
Each push of the
OUTPUT
key cycles through
the following modes:
