Hioki 3283 - Page 49

33
Chapter 5 Specifications
Insulation resistance
Clamp core - circuitry: 630 kilohms
min.
Location for use
Indoor, altitude up to 2000 m
Applicable standards
Safety:
EN61010-1:1993+A2:1995
Voltage input: Pollution level 2,
overvoltage categoryⅢ (expected
transient overvoltage: 4000 V)
EN61010-2-032:1995
EN60529:1991 IP40 (protected
against access to hazardous parts
with a wire)
EMC:
EN55011:1991+A2:1996 Group1
ClassB
EN50082-1:1992
Maximum conductor
diameter for
measurement
φ40 mm max.
Operating
temperature and
humidity range
0to40℃, 80%RH or less (no
condensation)
Temperature
characteristics
In 0 to 40℃ range: 0.05×accuracy
specifications/℃
Storage temperature
range
-10 to 50℃ (no condensation)
Power source
One 6F22 (006P) 9 V battery or
9445 AC ADAPTER (UP01211090,
POTRANS) (option)
Maximum power
consumption
100 mVA
Battery life
50 hours max. (continuous, no load)
External dimensions
62(W)×225(H)×39(D) mm
