Basic instruction on how to use the instrument
1
Connect the test lead to the
instrument.
(Black) (Red)
Hold down for
at least 1 s.
2
Turn on the instrument.
Set the date and time when using
the instrument for the rst time.
(p. 43)
3
Choose a resistance range.
(p. 47)
4
Choose a voltage range.
(p. 47)
5
Enable the automatic hold and
automatic memory functions.
(The
and
segments will appear.)
When the measured values become stable, the
display will automatically freeze them.
See “3.6 Automatic Hold Function” (p. 59).
Immediately after the display freezes measured
values, the instrument will automatically save them.
See “5.3 Automatic Memory Function” (p. 87).
HIOKI BT3554F961-00HIOKI BT3554F961-00
