53
Accuracy Table
DC current (Measurement value/MAX/MIN/AVG)
Range
(Accuracy guarantee
range)
Resolution
Measurement accuracy
(Values apply regardless of whether the lter is on or off.)
600.0 A (±1.0 A to ±600.0 A)* 0.1 A ±1.3% rdg.±0.3 A
2000 A (±10 A to ±2000 A) 1 A ±1.3% rdg.±3 A
Auto range movement threshold: 6000 counts or more for upper range, 540 counts or less for lower range.
* For 30.0 A or less, add 0.5 A to the measurement accuracy.
DC current (PEAK MAX/PEAK MIN)
Range
(Accuracy guarantee
range)
Resolution Measurement accuracy
600.0 A (±10 A to ±1500 A) 1 A ±1.3% rdg.±7 A
2000 A (±10 A to ±2300 A) 1 A ±1.3% rdg.±7 A
(±2301 A to ±2840 A) 1 A ±6.0% rdg.±7 A
