66
Accuracy Table
15
Diode (same for all models)
Overload protection: Lower of 1700 V DC/1000 V AC or 2×10
7
V • Hz (energized for 1 minute)
Overload current: 30 mA or less at steady state, 1.5 A or less at transient state
Range
(Accuracy guarantee
range)
Resolution Short-circuit current
Measurement
accuracy
Open terminal
voltage
1.800 V (0.000 V to 1.800 V) 0.001 V 200 µA±20% ±0.7% rdg.±0.005 V 2.0 V DC or less
Beeping buzzer tone at forward connection (0.15 V to 1.8 V).
Continuous buzzer tone and red backlight lights up if less than 0.15 V.
16
Electrostatic capacity (same for all models)
Overload protection: Lower of 1700 V DC/1000 V AC or 2×10
7
V • Hz (energized for 1 minute)
Overload current: 30 mA or less at steady state, 1.5 A or less at transient state
