68
Accuracy Table
Temperature (Measurement value/MAX/MIN/AVG)
Thermocouple type Range Resolution Accuracy*
1
K
-40.0°C to 400.0°C 0.1°C ±0.5% rdg.±3.0°C
-40°F to 752°F*
2
0.1°F ±0.5% rdg.±5.4°F
*1: In an environment where the temperature of the instrument is ±1°C and stable, the accuracy is specied.
*2: Instrument can be made to display readings in Fahrenheit (°F) by means of special operation.
18
Electric charge detection
During voltage detection, a continuous buzzer sounds and the red warning backlight lights up.
Range (detection sensitivity) Detection voltage range* Detection target frequency
Hi 40 V AC to 600 V AC 50 Hz/60 Hz
Lo 80 V AC to 600 V AC 50 Hz/60 Hz
* In contact with the insulated wire that is equivalent to IV2 mm
2
.
