12
Overview
1.2 Part Names
Front Rear
(CM4376)
7
9
5
1
2
8
12
3
11
4
10
6
1 Operation grip
2 Jaw open/closed mark
(The jaws are open if the mark is not
showing.)
3 SHIFT key
(Selects function indicated in blue lettering.)
4 Jaw
5 Barrier
6 Serial number (The serial number consists of
9 digits. The rst two (from the left) indicate
the year of manufacture, and the next two
indicate the month of manufacture.)
7 Rotary switch
8 HOLD key
9 LCD
10 Battery cover
11 Operation keys
12 Measurement terminals
