Other Measurement Functions
索
引
6
5
4
3
2
1
2.3 Other Measurement Functions
Voltage
Switch the range

DC voltage polarity detection function (p. 31)
If the measured value is negative, the buzzer will sound,
and the display will turn red (threshold: −10 V).
(DC V)
2 3
DC成分の波形
AC成分の波形
DC+AC成分の波形
DC成分の波形
AC成分の波形
DC+AC成分の波形
Hz
AUTO
DC成分の波形
AC成分の波形
DC+AC成分の波形
e.g.: commercial power supply (AC voltage measurement)
Do not touch.No overvoltage
(Red ash)
NO
(AUTO AC/DC)
(AC+DC V)
(AC V)
Red Black
NO
1
(Frequency)
