18
Current Measurement
Filter Function
FILTER OFF FILTER ON
Measured value including noise
Measured value with reduced noise
Press for 1 sec.
Frequency [Hz]
Measured value [A]
Frequency characteristics when using the
lter function (100 A input)
FILTER OFF
FILTER ON Passband 100 [Hz]
Turn off the lter function when performing
measurement of power supply frequencies in excess
of 100 Hz, for example on an aircraft or ship.
Filter OFF
