HireTech HT8 - Service & Repair

HT MULTI SPEED PARTS LIST8-
095 167210 1 Retainer Seal
096 010210 4 Screw
097 166906 2 Pulley Fan
098 915028 6 Key
099 167704 1 Shaft Fan
100 010220 4 Screw and Washer Set
101 980648 2 Washer
102 980626 3 Washer Lock
103 920132 3 Nut
104 010180 4 Brush Motor
109 010230 4 Brush Spring
110 911662 1 Lead Motor Assembly
111 167302 1 Ring Retaining
113 168104 1 Sleeve
114 163104 1 Field 110/120 Volt 8HT
114 163112 1 Field 220/240 Volt 8HT
115 962401 2 Screw
116 166172 1 Baffle Motor
117 167204 1 Retainer Baffle
118 160408 1 Armature 110/120 Volt
118 160412 1 Armature 220/240 Volt
119 980004 2 Spacer
121 163008 1 Fan Motor
123 167802 1 Shield Pulley
124 902550 2 Bearing Drum Shaft
125 163682 2 Bearing Armature
126 062003 2 Clamp Bearing
127 962345 10 Screw
128 168212 1 Spacer Motor Pulley
129 163304 3 Flange Pulley
130 166909 1 Pulley Motor
18
Ref. Pack DescriptionPSTK
Qty.
Ref. Pack DescriptionPSTK
Qty.
140 163789 1 Brush Block Assembly
142 962411 1 Screw
143 162006 1 Clamp Bearing
144 925113 1 Pin Drum Shaft
145 161108 1 Bush Bearing
146 168206 1 Spacer Bearing
149 167716 1 Shaft Drum
152 168209 1 Spacer Bearing
159 166916 1 Pulley Drum
164 903260 1 Belt Drum 3/4" (19mm) Wide
165 903273 1 Belt Fan 1/2" (13mm) Wide
167 162312 1 Drum Cover Kit
168 162532 1 Drum Assembly Complete
169 100327 13 Screw
170 163012 1 Assembly Fan Intake
173 163668 1 Lifting Pin Assembly
174 000920 2 Screw Clamp Bar (screwdriver slot)
174 163657 2 Screw Clamp Bar (coin slot)
175 020045 1 Clamp Bar Paper (reversible)
176 164607 3 Insert Drum Kit
179 024800 1 Owners Manual & Operating Instructions
Multi-Speed
200 101219 1 Floor Roller Assembly
201 163827 1 Kit Moulded Guards (Grey)
201 163873 1 Kit Moulded Guards (Grey, excl. Tube Exhaust)
250 011860 2 Service Tool - Extractor Seal
250 024500 1 Test Lead
250 024502 1 Test Lead ( )NA
250 100325 1 Service Tool - Clamp Drum Cover
250 163822 1 Service Tool - Drum Insert Removal
250 163857 1 Service Tool - Adjuster Floor Roller
