CONTENTS
WARNING i
MAINS CABLE WIRING PLUG- i
SPARE PARTS i
SPECIFICATION 1
SAFETY 1,2
SET UP
Assembly and Transport 2
Installing Abrasive Paper 2
PREPARATION 2,3
OPERATION 3,4
FLOOR SANDING TECHNIQUE
Drum Floor Sander 4,5
Disc Floor Sander 5
Orbital Floor Sander 5
Hand Sanding 5,6
FLOOR TYPES
Sanding Plank & Strip Floors 6
Veneered, Laminated & Thinner Floors 6
Parquet & Block Floors 6
Between Coats of Finish (Varnish) 6
FLOOR SANDER ABRASIVE GUIDE 7
SERVICE AND ROUTINE MAINTENANCE
8 Multi-Speed Control Unit 8,9HT
General 8
Visual Inspection 8
Drive Belts 8
Dust Control System 8
Lubrication 9
Sanding Drum 10
Care of Motor 10,11
Fitting a New Switch Multi-Speed 11,12
Fitting a new Controller Multi-Speed 12
Electrical Testing 13
FAULT FINDING 14
HT PARTS DRAWING8-1.2 15,16
HT PARTS LIST8-1.2 17,18
HT CIRCUIT DIAGRAM8-1.2 19
DECLARATION OF CONFORMITY 20
SERVICE REPAIR& 21
LIMITED WARRANTY 22
WARNING
For safe operation of this machine, read and understand all instructions. Look for the ‘warning/caution’ symbol.
This symbol means that if you do not follow the instructions injury can occur to the operator and
damage to the machine and floor may result.
MAINS CABLE WIRING PLUG-
Hiretech reserves the right to make changes or improvements to it's products without prior notice.
i
NORTH AMERICA
BLACK
WHITE
GREEN
BRASS
TERMINAL
SILVER
TERMINAL
EU
BLUE
BROWN
GREEN/
YELLOW
UNITED KINGDOM
BLUE
(N - )NEUTRAL
BROWN
(L - )LINE
GREEN YELLOW/
(E - )EARTH
SPARE PARTS
Use Hiretech genuine spare parts only for service and repair. Use of non-approved parts will void the product
warranty. See the back cover of this manual for the terms and conditions of the Hiretech Limited Warranty.
To Next Page
