Hirschmann MICE MS20 - Damped Vibration Immunity; Impulse-Shaped Magnetic Fields Immunity

58
Installation MS20/MS30
Release
11
07/2013
Damped vibration - DC supply connection
EN 61000-4-12
IEEE C37.90.1
line/ground — — — 2.5 kV
EN 61000-4-12
IEEE C37.90.1
line/line — — — 1 kV
Damped vibration - data line
EN 61000-4-12
IEEE C37.90.1
line/ground — — — 2.5 kV
EN 61000-4-12 line/line — — — ± 1 kV
Impulse-shaped magnetic fields
EN 61000-4-9 — — 300 A/m —
a. EN 61131-2, CE, FCC – applies to all devices
b. Merchant Navy (GL, ABS, BV, DNV, KR, LR, RINA) – applies to devices with the certification codes B, E, H, S
c. EN 50121-4 – applies to devices with the certification codes E, H, S
d. EN 61850-3, IEEE 1613 – applies to devices with the certification codes H, S
EMC interference
immunity
Standard
applications
a
Marine
applications
b
Railway
applications
(trackside)
c
Sub-station
applications
d
