Hirschmann MICE MS20 - Stability (Vibration and Shock)

Installation MS20/MS30 Release
11
07/2013
59
Stability Standard
applications
a
a. EN 61131-2, CE, FCC – applies to all devices
Marine
applications
b
b. Merchant Navy (GL, ABS, BV, DNV, KR, LR, RINA) – applies to devices with the certification codes B, E, H, S
Railway
applications
(trackside)
c
c. EN 50121-4 – applies to devices with the certification codes E, H, S
Sub-station
applications
d
d. EN 61850-3, IEEE 1613 – applies to devices with the certification codes H, S
IEC 60068-2-6, test Fc Vibration — 2 Hz ... 13.2 Hz
with
1 mm amplitude
— 2 Hz ... 9 Hz with
3 mm amplitude
5 Hz ... 8.4 Hz with
3.5 mm amplitude
— 5 Hz ... 8.4 Hz with
3.5 mm amplitude
5 Hz ... 8.4 Hz with
3.5 mm amplitude
— — — 1 Hz ... 200 Hz
with 1 g
8.4 Hz ... 150 Hz
with 1 g
8.4 Hz ... 150 Hz
with 1 g
8.4 Hz ... 150 Hz
with 1 g
—
— — — 200 Hz ... 500 Hz
with 1.5 g
IEC 60068-2-27, Test Ea Shock 15 g at 11 ms 15 g at 11 ms 15 g at 11 ms 15 g at 11 ms
