 Network range
Note: The line lengths specified for the transceivers apply for the
respective fiber data (fiber attenuation and BLP/dispersion).
AU port
Length of an AUI cable max. 50 m
Table 15: AUI port
TP port
Length of a twisted pair segment max. 100 m/328 ft (for cat5e cable)
Table 16: TP port 10BASE-T / 100BASE-TX / 1000BASE-T
Product
code
Wave
length
Fiber System
attenuati
on
Example
for F/O
line
length
a
a. including 3 dB system reserve when compliance with the fiber data is observed
Fiber
attenuation
BLP/
dispersion
-F4 MM 820 nm 50/125 µm 0-9.5 dB 0-2.1 km 3.0 dB/km 400 MHz*km
-F4 MM 820 nm 62.5/125 µm 0-12.5 dB 0-3.0 km 3.2 dB/km 200 MHz*km
Table 17: F/O port 10BASE-FL
Prod
uct
code
Wave
length
Fiber System
attenuati
on
Example
for F/O
line length
a
a. including 3 dB system reserve when compliance with the fiber data is observed
Fiber
attenuation
BLP/
dispersion
-M2,
-M4
MM 1300 nm 50/125 µm 0-8 dB 0-5 km 1.0 dB/km 800 MHz*km
-M2,
-M4
MM 1300 nm 62.5/125 µm 0-11 dB 0-4 km 1.0 dB/km 500 MHz*km
-S2 SM 1300 nm 9/125 µm 0-16 dB 0-30 km 0.4 dB/km 3.5 ps/(nm*km)
-L2 LH 1550 nm 9/125 µm 7-29 dB 24-86 km 0.3 dB/km 19 ps/(nm*km)
-P4 MM POF 650 nm 980/1000 µm 0-15.5 dB 0-65 m 200 dB/km 10 MHz*km
-P4 MM HCS 650nm 200/230 µm 0-7 dB 0-140 m 10 dB/km 17 MHz*km
-P9 MM POF 650 nm 980/1000 µm 0-14.0 dB 0-55 m 200 dB/km 10 MHz*km
-G2 LH+ 1550 nm 9/125 µm 14-47 dB 67-176 km 0.25 dB/km 19 ps/(nm*km)
Table 18: F/O port 100BASE-FX
