14
Disclaimer: All products, product specifications, and data are subject to change without notice to improve reliability, function, design or
otherwise.
PRODUCT SPECIFICATIONS
Model Name
32H5E / 32H5E1 / 32H5508 / 32H5020E / 32H5030E / 32H5040E / 32H5050E / 32H5070E /
32H5080E
Dimension
(W × H × D)
Without Stand 28.9 × 17.1 × 3.7 inches
(734 × 434 × 93 mm)
With Stand 28.9 × 18.7 × 6.7 inches
(734 × 474 × 171 mm)
Weight Without Stand 9.5 lbs (4.3 kg)
With Stand 9.7 lbs (4.4 kg)
Active Screen Size (Diagonal) 31.5 inches
Screen Resolution 1366 × 768
Audio Power 7 W + 7 W
Power consumption 50W
Power Supply 100 - 240V
50/60Hz
Receiving
systems
Analog NTSC
Digital ATSC / QAM
Ports 3 HDMI ports, 1 USB port, LAN port for Ethernet, 1 Digital Audio Output, 1 RF Input, 1 Earphone Audio Output,
1
RCA Composite Video Input, 1 left/right Audio Input for Composite
HDMI Input RGB / 60 Hz (640×480, 800×600, 1024×768), YUV / 60 Hz (480 I, 480 P, 720 P)
