TV Rear
TV Rear
NOTES
ANT2 Jack supports power supply for satellite antenna
(13/18V, 0.5A max.)
Check the jacks for position and type before making any
connections. Loose connections can result in image or
color problems. Make sure that all connections are tight and
secure.
Not all A/V devices have the ability to connect to a TV, please
refer to the user’s manual of your A/V device for compatibility
and connections procedure.
Before connecting external equipment, remove the mains
plug from the wall socket. Otherwise, it may cause electric
shock.
ANT 1
DVB-T/T2/C
ANT 2
DVB-S/S2
DC 5V 0.5A(MAX)
USB 1
DC 5V 1A(MAX)
USB 2
HDMI 3
(4K@30Hz)
HDMI 2
(4K@60Hz)
HDMI 1
(4K@60Hz)
ARC
HDMI 4
(4K@30Hz)
HDMI 4
(4K@30Hz)
Power input
VIDEO
VIDEO
L
L
R
R
AV IN
AV IN
COMMON INTERFACE
DIGITAL
AUDIO OUT
SERVICE
LAN
LAN
50"
55"/65"
Note: There's one screw at
the place of arrow and it is
usually covered by an AC
INPUT label.
