Hisense MR6DE - Page 28

25
MR6DE User Manual
Appendix
Signal formats supported by HDMI port
RGB/60Hz 640 × 480, 800 × 600, 1024 × 768
YUV/50Hz 576i, 576p, 720p, 1080i, 1080p, 2160p
YUV/60Hz 480i, 480p, 720p, 1080i, 1080p, 2160p
YUV/24Hz 25Hz 30Hz 3840 x 2160, 4096 x 2160
YUV420/50Hz 60Hz 3840 x 2160, 4096 × 2160
YUV444/50Hz 60Hz 3840 x 2160, 4096 × 2160
RGB444/50Hz 60Hz 3840 x 2160, 4096 × 2160
NOTE
HDMI standard and HDMI enhance are supported by the device. HDMI enhance (side HDMI) is
the default,which supports all formats listed above.HDMI standard only supports part of formats
listed above.If HDMI enhance is needed, you can tab menu under HDMI Version and select
HDMI enhance.
