14.4. IF Connector
14.5. PROGRAMMING Connector
14.6. S/PDIF Connector
Pin Description
1
S/PDIF
2
GND
14.7. DIGITAL AV Connector
Pin Description Pin Description
1
I2S Word Select
11
GND
2
I2S Serial Clock
12
Digital Video Pixel Clock
3
I2S Serial Data
13
Digital Video Y/Cb/Cr DATA7
4
GND
14
Digital Video Y/Cb/Cr DATA6
5
GND
15
Digital Video Y/Cb/Cr DATA5
6
GND
16
Digital Video Y/Cb/Cr DATA4
7
Internal Vertical SYNC
17
Digital Video Y/Cb/Cr DATA3
8
Internal Horizontal SYNC
18
Digital Video Y/Cb/Cr DATA2
9
GND
19
Digital Video Y/Cb/Cr DATA1
10
GND
20
Digital Video Y/Cb/Cr DATA0
Pin Description
1
IF +
2
IF -
3
GND
Pin Description
1
TXD
2
GND
3
RXD
