14.8. PCMCIA Connector
Pin Signal Description Pin Signal Description
1
GND Ground
35
GND Ground
2
D3 Data bit 3
36
CD1# Card Detect
3
D4 Data bit 4
37
MDO3 MPEG Data Out 3
4
D5 Data bit 5
38
MDO4 MPEG Data Out 4
5
D6 Data bit 6
39
MDO5 MPEG Data Out 5
6
D7 Data bit 7
40
MDO6 MPEG Data Out 6
7
CE1# Card Enable
41
MDO7 MPEG Data Out 7
8
A10 Address bit 10
42
CE2# Card Enable
9
OE# Output Enable
43
VS1# Voltage Sense 1
10
A11 Address bit 11
44
IORD# I/O Read
11
A9 Address bit 9
45
IOWR# I/O Write
12
A8 Address bit 8
46
MISTRT MPEG Data In Start
13
A13 Address bit 13
47
MDI0 MPEG Data In 0
14
A14 Address bit 14
48
MDI1 MPEG Data In 1
15
WE# Write Enable
49
MDI2 MPEG Data In 2
16
IREQ# Interrupt Request
50
MDI3 MPEG Data In 3
17
VCC Supply Voltage
51
VCC Supply Voltage
18
VPP
Programming and
Peripheral Supply
52
VPP
Programming and
Peripheral Supply
19
MIVAL MPEG Data In Valid
53
MDI4 MPEG Data In 4
20
MCLKI MPEG Data Clock Input
54
MDI5 MPEG Data In 5
21
A12 Address bit 12
55
MDI6 MPEG Data In 6
22
A7 Address bit 7
56
MDI7 MPEG Data In 7
23
A6 Address bit 6
57
MCLKO MPEG Data Clock Output
24
A5 Address bit 5
58
RESET Card Reset
25
A4 Address bit 4
59
WAIT# Extend bus cycle
26
A3 Address bit 3
60
INPACK# Input Port Acknowledge
27
A2 Address bit 2
61
REG#
Register select & I/O
Enable
28
A1 Address bit 1
62
MOVAL MPEG Data Out Valid
29
A0 Address bit 0
63
MOSTRT MPEG Data Out Start
30
D0 Data bit 0
64
MDO0 MPEG Data Out 0
31
D1 Data bit 1
65
MDO1 MPEG Data Out 1
32
D2 Data bit 2
66
MDO2 MPEG Data Out 2
33
IOIS16# I/O Port Is 16-bit
67
CD2# Card Detect
34
GND Ground
68
GND Ground
