Hitachi CP-RX60 - PICTURE menu

27
Multifunctional settings
PICTURE menu
Item
Description
BRIGHT
Using the buttons ▲/▼ adjusts the brightness.
: Light

Dark
CONTRAST
Using the buttons ▲/▼ adjusts the contrast.
:
Strong

Weak
GAMMA
Using the buttons ▲/▼ switches the
GAMMA mode.
#1 DEFAULT

#1 CUSTOM

#2 DEFAULT
#3 CUSTOM

#3 DEFAULT

#
2
CUSTOM
To adjust #1 CUSTOM, #2 CUSTOM or #3 CUSTOM
Selecting
a mode of CUSTOM
and then
pressing the button ►
or the ENTER button
displays a dialog to aid you in adjusting the
mode.
This function is useful when you want to
change the brightness of particular tones
.
Choose
an item
using the buttons ◄/►, and
adjust the level using the buttons ▲/▼.
Using a test pattern
Y
ou can display a test pattern for checking the effect of your
You can display a test pattern for checking the effect of your Y
adjustment by pressing the ENTER button
.
Each time you press the ENTER button, the pattern changes as
below.
No pattern

Gray scale of 9 steps
Ramp

Gray scale of 15 steps
Eight of equalizing bars corresponds to eight of tone level of test
pattern except the darkest in the left end. If you want to adjust
the 2nd tone from left end on the test pattern, use the equalizing
adjustment bar “1”. The darkest tone at the left end of the test
pattern cannot be controlled with any of equalizing adjustment bar.
With the PICTURE menu, items shown in the table below
can be performed.
Choose an item using the cursor buttons ▲/▼ on the
projector or remote control, and press the cursor button ►
on the projector or remote control, or the ENTER button on
the remote control to progress. Then perform it referring to
the following table.
MENU
[
RGB
]
:SELECT
INPUT
SETUP
SCREEN
OPTION
EASY MEN
U
BRIGHT
CONTRAS
T
GAMMA
COLOR TEMP
COLOR
TINT
SHARPNES
S
PROGRESSIVE
MY MEMOR
Y
+0
+0
DEFAULT
1
HIG
H
+0
+0
+0
TURN OFF
SAVE
1
1
+0
2
+0
3
+0
4
+0
5
+0
6
+0
7
+0
8
+0
GAMMA
[
CUSTOM 1
]
ENTER :
Ramp
DEFAULT
CUSTO
M
DEFAULT
CUSTO
M
GAMMA
DEFAULT
CUSTO
M
#1
#2
#3
