Hitachi CP-S210 User Manual

5
AC inlet
11
VIDEO port
10
AUDIO port
(from a computer)
10
S-VIDEO port
10
COMPONENT VIDEO - Y
10
COMPONENT VIDEO - CB/PB
10
COMPONENT VIDEO - CR/PR
10
AUDIO R port
L port
(from a video equipment)
10
10
Power switch
14
RGB port
10
CONTROL
port
10
Projector (Rear/Left)
STANDBY/ON
INPUT
POWER
LAMP
TEMP
MENU
POWER indicator
tells the state of power
supply. Refer to the section
“Power ON/OFF”.
INPUT button
toggles between the signal
ports.
MENU buttons
operate the menu function.
STANDBY/ON
button
prepares for turning the
power on/off. Refer to the
section “Power ON/OFF”.
TEMP indicator
lights or blinks when any
problem about internal
temperature has happened.
LAMP indicator
lights or blinks when any
problem about the lamp has
happened.
RGB VIDEO
S-VIDEO
COMPONENT VIDEO
ACIN
Part Names (continued)
The Projector (continued)
15 14 39
39
22
14
